LED-2150

  • The LED-2150 is a powerful luminaire that has been designed to meet a wide variety of installation locations.
    With the various mounting options it can be used as a flood light or as an area light.
    With the LEDs mounted on the large heatsinks the fixture can maintain a high lumen output while keeping the LED modules at a cool temperature.

    ​-UL and CUL listed for wet locations.
    -Heavy duty die-cast aluminum powder coating, corrosion resistant hardware.
    -UV stabilized powder coated finish.
    -Heat and impact resistant tempered glass.
    -Optional 347V with adder.
    -Optoinal 10kV surge protector with adder.
    -Optional NEMA photo control with adder.
    -N3 = NEMA 3  (Wide distribution)
    -N5 = NEMA 5
    -N7 = NEMA 7   (Narrow distribution)
    -Finish:  Bronze.  Color option with adder.
    -Mounting Options:
    -LED-2150-SF:  Slip Fitter
    -LED-2150-TR:  Trunnion
    -LED-2150-U:    U-Bracket
  •   Download Datasheet
    Model Number LED-2150-L3
    System Wattage 150W 197W
    Delivered Lumens (Lms.) 16061 lm** 23000 lm**
    Efficacy (Lm/W) 107 lm/w 117 lm/w
    Color Rendering Index (CRI) 70+
    Color Temperature (CCT) 5000K
    Input Voltage 120~277V
    MA 1200MA 1150MA
    Equivalent 250W MH 400W MH
    Dimensions (Inches) 15.2"x 9.65" x16.3" inches
    Kgs (LB) 12.88 kgs / 28.37 lb

    Build Your Order
    Model
    Number
    System
    Wattage
    Distribution Voltage CCT Electrical Housing
    Finish
    Mounting
    LED-2150-L3 150W
    197W
    NEMA (3X3)**
    NEMA (5x5)**
    NEMA (7x7)**
    120-277V
    347V**
    5000K
    CUSTOM**
    Photo control**
    Surge protector 10K**
    480V Max Receptacle**
    Bronze
    Black**​
    CUSTOM**
    Trunnion**
    Slip Fitter**
    U Bracket**
    **Optional with adder
      *Different LED Kelvin temperature available with 5-6 week lead time. Please call for quote.
    **Disclaimer: This test report was produced in accordance with IES LM-79 photometric testing protocol for luminaires, using a single representative test fixture.
       Actual production units may vary from the values reported here by up to +/-10%.
