LED-150/ LED-300/ LED-450

  • Ideal for parks, building, sports field, and other general applications.
    The lighting fixture is a unique and flexible system, comprised of self-contained modular elements, representing variability in both lumen output and optics capabilities.
    The lighting fixture can be specified in one, two or three-150-watt module configurations where each module can have one of the three available optical distributions.

    -UL and CUL listed for wet location.
    -Solid construction die-cast aluminum frame.
    -Solid extruded aluminum body .
    -UV stabilized powder coated finish.
    -Various light distribution.
    -Various optical lenses available with adder.
    -U-Bracket mount.
    -Finish: Bronze.  Color option with adder.


  •  Download Datasheet
    Model Number LED-150 LED-300 LED-450
    System Wattage 150W 300W 450W
    Delivered Lumens (Lms.) 15178  30114  45559
    Color Rendering Index (CRI) 70+
    Color Temperature (CCT) 5000K
    Input Voltage 120~277V
    MA 700MA
    Equivalent 250W MH 400W MH 1000W MH
    Dimensions (Inches) 27" * 7.64" * 6.81"   27" * 12.4" * 6.81" 27" * 20.3" * 6.81"
    Weight (kg / lb) 10.31kg / 22.7lb 16.37kg / 36lb 23.2kg / 51.1lb


    Build Your Order
    Model
    Number
    System
    Wattage
    Distribution Voltage CCT Housing
    Finish
    Mounting Accessories
    LED-150
    LED-300
    LED-450
    150W
    300W
    450W
    Wide
    Narrow
    120-277V 5000K
    • Custom
    Bronze
    • Custom
    U-Bracket N/A
    ** Optional with adder
    Different LED Kelvin temperature available with 5-6 week lead time. Please call for quote.
    **Disclaimer: This test report was produced in accordance with IES LM-79 photometric testing protocol for luminaires, using a single representative test fixture.
    Actual production units may vary from the values reported here by up to +/-10%.
