Grandlite International Corp

LED-1860-L2-SFB

  • Thisnewlydesignedluminairewithbuiltinheatsinkincastingfeaturingitsversatilitythatcanbeservedaswalllight,floodlightandetc.IncorporatedwithhighperformanceLEDmodulealongwithhighqualityopticalreflector,thisfixtureperformsefficientlyandsteadilyagainstharshoutdoorenvironment.-ULandCULlistedforwetlocation-Solidconstructiondie-castaluminumbody-​UVstabilizedpowderc..
  •  Download Datasheet
    Model Number LED-1860-L2
    System Wattage 60 82
    Delivered Lumens (Lms.) 6743 lm** 7970 lm**
    Efficacy (Lm/W) 112 97
    Color Rendering Index (CRI) 70+
    Color Temperature (CCT) 5000K
    Input Voltage 120~277V
    MA 700 MA 950 MA
    Equivalent 250W MH
    Dimensions (Inches) 7.08"x9.09"x3.93"
    Weight (kg / lb) 2.86 kg / 6.3lb

    Build Your Order
    Model
    Number
    System
    Wattage
    Distribution Voltage CCT Electrical Housing
    Finish
    Mounting
    LED-1860-L2 60W
    82W


    N/A 120-277V 5000K
    CUSTOM**
    Photo control** Bronze
    Black**​
    CUSTOM**
    Quick mount
    Trunnion**
    Brackets**
    Slip Fitter**
    **Optional with adder
      *Different LED Kelvin temperature available with 5-6 week lead time. Please call for quote.
    **Disclaimer: This test report was produced in accordance with IES LM-79 photometric testing protocol for luminaires, using a single representative test fixture.
       Actual production units may vary from the values reported here by up to +/-10%.
